VR2138W

Fixed

Recessed Downlight

VR213

Fixed Recessed Downlight

Designed for high-efficiency general lighting, this fixed architectural downlight delivers smooth, uniform, and glare-free illumination, making it the ideal solution for modern residential and commercial spaces requiring clean, stable lighting.

Technical Specifications

CODE VR2138W VR21310W VR21316W VR21324W VR21336W
Dimension(mm) Φ118x48mm Φ143X52mm Φ178X57mm Φ192X58mm Φ232X62mm
Cutout (mm) Φ90mm Φ115mm Φ145mm Φ160mm Φ205mm
System power (W) 8W 10W 16W 24W 36W
Input Voltage(V) 220-240VAC 50/60Hz 220-240VAC 50/60Hz 220-240VAC 50/60Hz 220-240VAC 50/60Hz 220-240VAC 50/60Hz
Light Source Osram SMD Osram SMD Osram SMD Osram SMD Osram SMD
SDCM <5 <5 <5 <5 <5
CCT(K) 3000K/4000K standard. Different CCT upon request. 3000K/4000K standard. Different CCT upon request. 3000K/4000K standard. Different CCT upon request. 3000K/4000K standard. Different CCT upon request. 3000K/4000K standard. Different CCT upon request.
Luminous (lm) ±5% 120 lm/W 120 lm/W 120 lm/W 120 lm/W 120 lm/W
CRI Ra>80 Ra>80 Ra>80 Ra>80 Ra>80
Beam Angle (°) 120° 120° 120° 120° 120°
LED Driver External LED driver External LED driver External LED driver External LED driver External LED driver
Dimming Option On-off / 1-10v / Triac / Dali On-off / 1-10v / Triac / Dali On-off / 1-10v / Triac / Dali On-off / 1-10v / Triac / Dali On-off / 1-10v / Triac / Dali
UGR <19 <19 <19 <19 <19
IP Rating IP20 IP20 IP20 IP20 IP20
Product Colour White White White White White
Materials Aluminum Die-casting Aluminum Die-casting Aluminum Die-casting Aluminum Die-casting Aluminum Die-casting
Lifetime (hr) 50,000h 50,000h 50,000h 50,000h 50,000h
Operating Temp. -20°~50° -20°~50° -20°~50° -20°~50° -20°~50°

Ordering Options

VR2138W CCT
VR2138WC3 3000K
VR2138WC4 4000K
VR21310W CCT
VR21310WC3 3000K
VR21310WC4 4000K
VR21316W CCT
VR21316WC3 3000K
VR21316WC4 4000K
VR21324W CCT
VR21324WC3 3000K
VR21324WC4 4000K
VR21336W CCT
VR2138WC3 3000K
VR2138WC4 4000K
